Pro dual band mobile signal booster to improve calls & 3G 4G 5G services

(32 customer reviews)

$356.00

Filters Sort results
Reset Apply
Key Features
Application
Network Services
Frequency Bands
700
/
900
MHz
(Band
28
|
8
)
Coverage
up to 150m²
Ideal for
⋅
⋅
Providers Supported
A Standard Kit includes
1x Booster + Power Adapter
1x Indoor Ceiling Antenna
1x Outdoor General LPDA Antenna
1x 15-meter Low Loss Cable
1x 5-meter Low Loss Cable
2-Year Warranty
30-Day Money Back
Need Extra internal antenna(s) ?
None 1x ceiling antenna (omni-directional) +$35.00 1x panel antenna (directional) +$49.00 2x ceiling antennas (omni-directional) +$63.00 1x ceiling antenna + 1x panel antenna +$77.00 2x panel antennas (directional) +$91.00

  • Safe And Secure Shopping
  • Delivery Time 5-7 Business Days. Trackable Delivery.
  • 30-Day Money-Back Guarantee
  • Price Match Guarantee
  • info@maxsignalboosters.com

Description

Filters Sort results
Reset Apply
In our day and age, it's vital to have a quality connection with the world. And if the outside signal is just not strong enough, it can be a cause of constant stress. Don’t subject yourself to that and check out this great device designed to enhance your signal in no time! This model works with amazing perfect performance for crystal clear voice and data, supporting all major providers, an excellent option for you to choose now.Note: 5G services are subject to provider’s signal coverage.
What makes our boosters different?
How to install the booster kit?
1. Find a good stable signal source outside of your property, in an open space, preferably on a higher altitude. If possible, roof top. Place outdoor antenna there in a way that(A) for directional antenna, i.e. LPDA, Yagi or Panel antenna, its direction points to the cell tower.(B) for omni-directional antenna, i.e. Pipe antenna, its direction points to sky vertically and without obstacles around, DO NOT care cell tower direction.2. Connect the outdoor antenna to “Outdoor ANT” port of the booster with a 15-meter cable or enough length cable3. Place indoor antenna at the central site of your preferable coverage, without obstacles around, and connect indoor antenna to “Indoor ANT” port of the booster with a 5m cable4. Power on the booster, check working status
Easy to understand booster working status
Power LED
Down Link LED DL/P
Power ON
No signal
No power
Good working
Best working
Up Link LED UL/P
dark, no calls
flicker, calling
fixed RED, Alarm
In Alarm state, should power off the booster and re-check installation. Trouble shooting in user's manual.
Technical Specifications
Frequency Bands
Band
28
|
8
Linear Gain (UL/DL)
Upon outside signal conditions
Output Signal Power
Upon coverage
ALC/AGC Range
≥ 20dB
MGC Adjustment Range (optional)
Max 31dB in step of 1dB
Noise Figure @ Full Gain
≤ 6dB
In Band Ripple
≤ 5dB
Group Delay
≤ 5μs
VSWR
≤ 1.8dB
Spurious Emission
9KHz ~1GHz ≤ -36dBm/100KHz1GHz ~12.5GHz ≤ -30dBm/1MHz
Inter-modulation
≤ -40dBc
Return loss
≤- 8 dB
Max. Input Power Without Damage
0 dBm
Frequency Stability
≤0.01ppm
MTBF
>50000 hours
System Impedance
50Ω
AC Power Requirements
100 ~ 240VAC / 45 ~ 65Hz
CE certification
RED CE
